| Control software |
| • |
free programmable with CARE software |
| • |
programmable with standard ModAL software modules |
|
| Hardware inputs |
input modules available for:
| • |
measurement of temperature, relative humidity, pressure etc. |
| • |
contact status from relays, thermostats etc. |
|
| Hardware outputs |
output modules available for:
| • |
control devices like servomotors |
| • |
switching devices like pumps, ventilators |
|
| Operator panels |
RS232 port available for operator panel XI581AH or XI582AH; this panel can be used for adjustment of setpoints, alarm limits, fixing in/outputs, override functions etc. |
| Management applications |
XBS or EBI PC software can be applied for a central operator and all other building automation functions |
| Stand-alone operation |
yes |
| Bus system description |
| • |
communication bus (C-bus) for data exchange with other EXCEL 5000 controllers and for building automation management systems (max. 30 devices per bus) |
| • |
LonWorks(R) bus |
|
| Transceiver type |
LonWorks(R) FTT10A |
| Mounting |
module to be placed into housing for EXCEL 5000 plug-in modules (XS563/XS564 + XH561) |
| Protection class |
IP30 |
| Type of terminals |
pins for EXCEL 5000 terminal socket XS563/XS564 |
| Memory back-up |
| • |
for XC5010C: goldcap capacitor for 72 hours buffer |
| • |
for XC6010: Lithium battery for 30 days buffer |
|
| Power supply |
24 Vacdc | 40 VA |
