Technical Specifications for 1785-KE

Manufacturer Rockwell Automation
Brand Allen-Bradley
Relative Humidity: 5-95% without condensation.
Storage temperature: -40 to 85 Degree Celsius
Operating temperature: 0-60 Deg. Celsius.
Backplane current draw 1.2 A at 5VDC
DH+ cable 1770-CD
RS232-C transmission speed 110 to 19200 bps
DH+ transmission speed up to 57600 bps
Module Width Single Slot
Built-in ports One (1) Data Highway Plus; One (1) RS232-C
Compatible controllers PLC2, PLC3, PLC4, PLC5 controllers
Mounting 1771 Chassis
Product Description: Data Highway Plus Communication controller module
Part Number/Catalog No. 1785-KE
Module Type Communication Interface Module
Communication Ports DH+, DH+(1784-T50), and RS-232-C
Rate of Communication DH+ 57,600 bps, Switch-Selectable RS-232-C 110-1920
Power Requirement 1.2 Amperes at 5 Volts DC
Location 1771-I/O Rack
LEDs 1 Diagnosis/Status Per Channel
Max Modules Per System 4
Weight 0.3 lbs (0.1 kg)
Coating Conformal Coat
Required External Power None
Typical AC Signal Delay (Off) 29 (+/- 8) ms
Typical DC Signal Delay (Off) 30 (+/- 7) ms
Wiring Arm 1771-WN
Dimensions 4.5 x 12.4 x 6.3 in (115 x 317 x 160 mm)
UPC 10662468206645
