Description
Technical Specifications for 1771-TCM
| Manufacturer | Rockwell Automation |
| Module Type | Process Control I/O Module |
| Connecting cables | 1771-NC6 / 1771-NC15 |
| Input filtering | 6-pole low pass hardware filter |
| Calibration Interval | 6 months, then yearly |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1771-TCM |
| Compatible Sensors | B, E, J, K, R, S and T and +/- 105 mV |
| Number of Inputs & Outputs | 8 |
| Input/Output Resolution | 16-Bit Resolution or 15 Bits + Sign Bit |
| Analog Inputs | Thermocouple |
| Data Format | Natural Binary 16-Bit Integer |
| Backplane Current | 1.5 Amperes |
| I/O Connection Hardware | 1771-RTP1 |
| Required External Power | None |
| Analog Outputs | N/A |
| Slots | 1 Slot |
| Typical AC Signal Delay (Off) | 29 (+/- 8) ms |
| Typical DC Signal Delay (Off) | 30 (+/- 7) ms |
| Wiring Arm | 1771-WN |
| Dimensions | 4.5 x 12.4 x 6.3 in (115 x 317 x 160 mm) |
| UPC | 10662468103418 |
