Original price was: $ 560.00.Current price is: $ 500.00.

In stock



Manufacturer Rockwell Automation
Wiring Arm 1771-WH; 1771-WHF
Storage Temperature: -40 to 185oF
Operating temperature: 32 to 131oF
Power Dissipation: 16.5 Watts (max); 3.7Watts (min.)
Minimum Load current: 50 mA per output @ 24VAC; 60 Hz
Output current per module: 8:00 AM
Output current per channel: 2A
Compatible I/O chassis: 1771-AM1 / 1771-AM2
Compatible 1771 chassis: Series A or B 1771-A1B, 1771-A2B, 1771-A3B, 1771-A3B1, 1771- A4B;
Output voltage range 10-60 VAC; 47-63 Hz
Number of Inputs 16
Brand Allen-Bradley
Part Number/Catalog No. 1771-OND
Module Type 24 VAC module
Backplane Current 700 mA @ 5VDC
Wiring Arm 1771-WH; 1771-WHF
Number of Outputs 16 Outputs
Voltage Category 24/48 Volts AC
AC Operating Voltage 10-60 Volts
Max Continuous Current Per Output 2 Amperes
Max Current Per Module 8 Amperes
Model Status Earlier Model
Coating Conformal Coat
Typical AC Signal Delay (Off) 45 (+/- 15) ms
Typical DC Signal Delay (Off) 50 ms
Mounting Rack Mountable
