Name: 140EHC20200
SKU: 6330
Price: 3994.00 USD
Availability: InStock

Description

Main
RANGE OF PRODUCT	Modicon Quantum automation platform
PRODUCT OR COMPONENT TYPE	High-speed counter module
NUMBER OF CHANNELS	2

Complementary
ADDRESSING REQUIREMENT	6 output words 6 input words
DATA FORMAT	2147483647 dec 32 bits 65535 dec 16 bits
COUNTING INPUT TYPE	Incremental or quadrature
COUNTING FREQUENCY	500000 Hz
DISCRETE INPUT VOLTAGE	< 30 V
OPERATING MODE	Incremental or quadrature discrete input
INPUT RESISTANCE	10 kOhm discrete input
OPERATING THRESHOLD	0…11 V single ended mode 24 V DC at state off 0…2 V single ended mode 5 V DC at state on 0 V single ended mode 12 V DC at state on 13…24 V single ended mode 24 V DC at state on 2…7 V single ended mode 12 V DC at state off >= 1.8 V differential mode 3.5…5 V single ended mode 5 V DC at state off
DISCRETE OUTPUT NUMBER	4
DISCRETE OUTPUT TYPE	Field Effect Transistor (FET)
DISCRETE OUTPUT VOLTAGE	0 V switch off DC 0.4 V switch on DC
LOAD CURRENT	0.5 A
MAXIMUM LEAKAGE CURRENT	0.4 mA state off
MAXIMUM VOLTAGE DROP	<0.4 V state on
PROTECTION TYPE	36 V transorb for discrete output
ISOLATION BETWEEN CHANNELS AND BUS	1780 Vrms for 60 s
FAULT TYPE	Loss of output field power
OUTPUT SHORT-CIRCUIT PROTECTION	Blown fuse 2.5 A
POWER DISSIPATION	4 + (0.4 x total module load current)
BUS CURRENT REQUIREMENT	650 mA
EXTERNAL POWER REQUIREMENT	19.2…30 V
RACK TYPE	Local Remote Distributed
LOCAL SIGNALLING	2 LEDs for channel status
MARKING	CE
CURRENT CONSUMPTION	<= 1050 mA at 24 V DC external power supply
MODULE FORMAT	Standard

Environment
RESISTANCE TO ELECTROSTATIC DISCHARGE	4 kV contact conforming to IEC 801-2 8 kV on air conforming to IEC 801-2
RESISTANCE TO ELECTROMAGNETIC FIELDS	10 V/m 80…1000 MHz conforming to IEC 801-3
AMBIENT AIR TEMPERATURE FOR OPERATION	0…60 °C
AMBIENT AIR TEMPERATURE FOR STORAGE	-40…85 °C
RELATIVE HUMIDITY	95 % without condensation
OPERATING ALTITUDE	<= 5000 m
STANDARDS	UL 508
PRODUCT CERTIFICATIONS	C-Tick.1 CSA No 142 FM Class 1 Division 2 UL
