Description
Description
| RANGE OF PRODUCT | Modicon Quantum automation platform |
|---|---|
| PRODUCT OR COMPONENT TYPE | Processor |
| SOFTWARE NAME | ProWORX 32 Concept |
| PROCESSOR NAME | 80486 |
| MATHEMATICAL COPROCESSOR | With |
| CLOCK FREQUENCY | 100 MHz |
|---|---|
| MEMORY DESCRIPTION | Internal RAM 2972 kB |
| EXACT TIME FOR 1 KINSTRUCTION | 0.1…0.5 ms LL984 |
| WATCHDOG TIMER | 250 ms |
| CLOCK DRIFT | +/-8 s/day at 0…60 °C |
| I/O WORDS | 30 I/32 O distributed 64 I/64 O max local 64 I/64 O remote |
| I/O WORDS/NETWORK | 500 I/500 O distributed |
| DROPS/NETWORK | 63 distributed |
| NUMBER OF DROPS | 31 remote |
| NUMBER OF NETWORK | 2 remote 3 distributed |
| BATTERY TYPE | Lithium 10 µA 420 µA |
| BATTERY CAPACITY | 1.2 Ah |
| BATTERY LIFE | 10 year(s) |
| SWITCH FUNCTION | Key switch |
| MARKING | CE |
| BUS CURRENT REQUIREMENT | 1250 mA |
| MODULE FORMAT | Standard |
| NET WEIGHT | 0.85 kg |
| PRODUCT CERTIFICATIONS | FM Class 1 Division 2 cUL |
|---|---|
| STANDARDS | CSA C22.2 No 142 UL 508 |
| RESISTANCE TO ELECTROSTATIC DISCHARGE | 4 kV contact conforming to IEC 801-2 8 kV on air conforming to IEC 801-2 |
| RESISTANCE TO ELECTROMAGNETIC FIELDS | 10 V/m 80…2000 MHz conforming to IEC 801-3 |
| AMBIENT AIR TEMPERATURE FOR OPERATION | 0…60 °C |
| AMBIENT AIR TEMPERATURE FOR STORAGE | -40…85 °C |
| RELATIVE HUMIDITY | 95 % without condensation |
| OPERATING ALTITUDE | <= 5000 m |
| UNIT TYPE OF PACKAGE 1 | PCE |
|---|---|
| NUMBER OF UNITS IN PACKAGE 1 | 1 |
| PACKAGE 1 HEIGHT | 5.0 cm |
| PACKAGE 1 WIDTH | 16.5 cm |
| PACKAGE 1 LENGTH | 31.0 cm |
| PACKAGE 1 WEIGHT | 524.0 g |
| UNIT TYPE OF PACKAGE 2 | S03 |
| NUMBER OF UNITS IN PACKAGE 2 | 7 |
| PACKAGE 2 HEIGHT | 30.0 cm |
| PACKAGE 2 WIDTH | 30.0 cm |
| PACKAGE 2 LENGTH | 40.0 cm |
| PACKAGE 2 WEIGHT | 4.183 kg |
